T82FC - helm-dual, X52 Tilt Mechanism and 2 - M66 steering cables
Featuring the T82FC Tilt helm with a Planetary Gear Design, the Rotech reduces steering effort and delivers more balanced loads on the steering wheel. This unique design also offers a wider wear area which reduces lost motion and improves durability. Centered on the main drive shaft, this helm requires less room behind the dash and is a direct “drop in” replacement for competing system; requiring no new holes for installation. The Rotech package also includes the M66 Universal Rotary Steering Cable with stainless steel output fittings for maximum longevity and smooth steering. (See how to choose the correct length when ordering)
Whats in the Box
T82FC - 38958 L dual cable steering helm, X52 - 39250 U and 2 - M66 Steering Cables
FEATURES AND TECHNICAL SPECIFICATIONS Tilt range of 48° and five locking positions Fast connect, simple installation Tilt device eliminates underdash movement Standard 3/4” tapered shaft - stainless steel All stainless steel cable output ends Corrosion resistant materials Lock-to-lock steering wheel turns: approx. 3.8 Stroke: 9” (228 mm) Maximum allowable steering wheel diameter: 16” (406 mm) Minimum steering cable bend radius: 7.9” (200 mm) T82FC steering systems are not to be used on boats equipped with engines that exceed the maximum horsepower rating of the boat For boats faster than 50 mph our hydraulic steering systems are recommended.
