UP25F 42462 D Front Mount Hydraulic Steering Helm displacement revolutions is 1.5 cu.in.
Available in four different displacement sizes compact design ball bearing piston race built-in lock valve for positive rudder lock Integral relief valve for over-pressure protection 3/4" tapered stainless steel shaft easily accessible lock valve and shaft seal for replacement cast iron rotor for greater durability and longer life convenient front of dash fill 1/4" NPT fitting for 3/8" tube complete with elbow fittings.
X56 - 39465 S square flange or X57 - 39464 P round flange permit to install the pumps in an intermediate dashboard position.
UP25F 42462 D Front Mount Hydraulic Steering Helm displacement revolutions is 1.5 cu.in.
Features available in five different displacement sizes compact design ball bearing piston race built-in lock valve for positive rudder lock Integral relief valve for over-pressure protection 3/4” tapered stainless steel shaft Easily accessible lock valve and shaft seal for replacement cast iron rotor for greater durability and longer life Includes 90° adjustable fittings for 3/8” tube UP45 F pump is ideal for double cylinder applications direct “drop-in” replacement for competing helms.
X56 - 40198 C square flange or X57 - 39464 P round flange permit to install the pumps in an intermediate dashboard position.
